Dankzij hun mechanische en elektrotechnische eigenschappen zijn de GIFAS-veiligheidsverdelers van massief rubber bij uitstek geschikt voor gebruik als transformatorbehuizing. Van wandverdelers tot inspectiewagens, GIFAS ELECTRIC is in staat om uw individuele klantoplossing te fabriceren.

Onze transformatoren hebben dezelfde eigenschappen als al ons massief rubberen verdeler behuizingen. Bijvoorbeeld de uitstekende demping van oscillatie- en stotenergie, de sterke bestendigheid tegen zuren en logen, de uitstekende bestendigheid tegen weersinvloeden, UV en ozon en een hoog elektrisch isolerend vermogen.

Voor meer informatie kunt u de PDF aan de linkerzijde bekijken of contact met ons opnemen! Wij horen graag van u!

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:2,500–3,500 VA
Voltage:230 V / 24 V / 230 V / 42 V
Versions:Block transformer

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:630–1,200 VA
Voltage:230 V / 230 V
Version:Block transformer ring core

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:320–500 VA
Voltage:230 V / 230 V
Version:Blocktransformer

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:2,500 VA
Voltage:230 V / 230 V
Version:Block transformer

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:2,000 VA
Voltage:230 V / 230 V
Version:Block transformer

Special features:

  • In-built thermocouple can be installed on request for tangential fan control
  • External screws are made from stainless steel and are captive
  • Easy to service designs as all parts are individually replaceable
  • Transformers according to VDE 0570, IEC 61558
  • Safety isolated housings according to VDE 0100 part 410

Technical specifications:

Power:120–160 VA
Voltage:230 V / 24 V / 230 V / 42 V
Version:Toroidal transformers
