Floor socket outlets

Floor socket outlets

with hinged or screw-on lid

Floor sockets with open screw lid and or with fillable hinged lid

Advantages of GIFAS floor sockets

  • Individual equipment: Schuko, CEE, data connection, compressed air
  • Available in the following versions: hinged lid, removable lid, screw lid
  • Floor socket outlet cover can be individually filled with floor covering
  • Depending on model, suitable for maintenance with wet sweepers (IP65)
  • Areas of application: Indoor or protected outdoor area
  • All models can be leveled
  • Load capacity up to 50kN (5t)

Floor sockets: Aesthetics and function in harmony

Floor sockets are used in many areas, whether in hotels or restaurants, in conference rooms and in public areas such as foyers or exhibition areas. Modern socket outlets for installation in the floor integrate unobtrusively into the architecture or in external flat surfaces in courtyards or company premises as well as in public areas.

The latter must have special properties and be specially constructed so that they can be driven over and walked on and are adequately protected against moisture and splash water at all times. The high-quality sockets from GIFAS meet precisely these requirements and are easy to handle and maintain, as they are generally installed flush with the floor.

Make your selection from our extensive range of floor sockets with hinged lids, removable lids or screw-on lids!

Floor sockets with hinged cover - FONTO

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

FONTO 2000

Floor socket with hinged cover,
1 x socket (power, data, etc.),
Dry and wet maintenance
110x95mm / installation depth approx. 75mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

FONTO 2005

Floor socket with hinged cover,
1 x socket (power, data, etc.),
Dry maintenance
110x95mm / installation depth approx. 75mm

LED Mastleuchte in hellgrau für Straßen und Parkplätze mit Sensor-Technik. Moderne Technik in schlankem Design

FONTO 4290

Floor socket with hinged cover,
2 x socket (power, data, etc.),
Dry and wet maintenance
119x119mm / installation depth approx. 83mm

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

FONTO 4295

Floor socket with hinged cover,
2 x socket (power, data, etc.),
Dry maintenance
119x119mm / installation depth approx. 83mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

FONTO 4301

Floor socket with hinged cover,
2 x socket (power, data, etc.),
Dry and wet maintenance
119x119mm / installation depth approx. 83mm

LED Mastleuchte in hellgrau für Straßen und Parkplätze mit Sensor-Technik. Moderne Technik in schlankem Design

FONTO 4308

Floor socket with hinged cover (fillable),
2 x socket (power, data, etc.),
Dry and wet maintenance
119x119mm / installation depth approx. 83mm

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

FONTO 8301

Floor socket with hinged cover,
8 x socket (power, data, etc.),
Dry and wet maintenance
240x240mm / installation depth approx. 95mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

FONTO 8308

Floor socket with hinged cover (fillable),
8 x socket (power, data, etc.),
Dry and wet maintenance
240x240mm / installation depth approx. 95mm

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

FONTO 9301

Floor socket with hinged cover,
4 x socket (power, data, etc.),
Dry and wet maintenance
320×240 mm / installation depth approx. 276.5mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

FONTO 9308

Floor socket with hinged cover (fillable),
4 x socket (power, data, etc.),
Dry and wet maintenance
320×240 mm / installation depth approx. 276.5mm

Floor sockets with screw cap - FONTO

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

FONTO 4970W

Floor socket with screw cover,
2 x socket (power, data, etc.),
Dry and wet maintenance
119x119mm / installation depth approx. 83mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

FONTO 5000

Floor socket with screw cover,
4 x socket (power, data, etc.),
dry and wet maintenance, round, Ø 156 mm / installation depth approx. 95 mm

Floor sockets with screw cap - MASSO

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

MASSO 3000

Floor socket with screw cover,
4 x socket (power, data, etc.),
Dry and wet maintenance
170x170mm / installation depth approx. 142mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

MASSO 4000

Floor socket with screw cover,
4 x socket (power, data, etc.),
Dry and wet maintenance
170x170mm / installation depth approx. 190mm

LED Mastleuchte in hellgrau für Straßen und Parkplätze mit Sensor-Technik. Moderne Technik in schlankem Design

MASSO 4010

Floor socket with screw cap,
1 x socket (CEE),
Dry and wet maintenance
170x170mm / installation depth approx. 190mm

LED-Strahler für Industrie und Gewerbe. Rüttelfester LED Strahler für Arbeitsplatz. Leistung 80W bis 120W.

MASSO 8000

Floor socket with screw cover,
6 x socket (power, data, etc.),
Dry and wet maintenance
170x170mm / installation depth approx. 255mm

LED-Hochleistungsstrahler 230W bis 1.350W. LED-Strahler für hohe Lichtpunkte und für die Ausleuchtung großer Flächen.

MASSO 8010

Floor socket with screw cover,
4 x socket (power, data, etc.) +1 x CEE
Dry and wet maintenance
170x170mm / installation depth approx. 255mm

Application examples

Looking for modern floor sockets?

We have the solution for your project. With our range of socket outlets with hinged or screw-on covers, you can rely on a functional and aesthetic distribution solution for the future. As a company, town or family business, with GIFAS you have a powerful partner at your side.

Finding the perfect solution together.

GIFAS Katalog Elektromobilität 2020

Summarized for you!

Our product catalog for floor sockets.

We have summarized our solutions for companies and cities in a catalog chapter so that you can read all the product details in a compact format. Download the current PDF. We hope you enjoy reading and discovering.

GIFAS as your competent partner for floor sockets and floor boxes

For more than 60 years, GIFAS has been successful in the fields of high-quality industrial products made of solid rubber, electrical solutions for professional use and in the low-voltage sector. Our development, manufacturing/production and Europe-wide distribution of high-quality components for power distribution are important sub-areas. We attach great importance to quality, which is reflected in our certification according to the DIN EN ISO9001:2015 standard. At the same time, we rely on an efficient environmental management system, which is certified in accordance with DIN EN ISO 14001:2009. We are happy to assist you with all your requirements and projects, from planning, consulting and development to design and installation. Get in touch with us!

Sockets for installation in the floor and other products for power distribution

Floor sockets play a key role in the implementation of efficient and targeted power distribution, especially in terms of safety. Depending on the design, the sockets can even be used outdoors in wet floors, splash water or adverse weather conditions. You can obtain both standard versions with fixed equipment and individually configurable components for power distribution. We specialize in individual customer requirements. A good example is the FONTO and MASSO series with hinged cover or screw cover, which can be leveled. These are floor sockets made of robust aluminum for applications with either earthing contact plugs, CEE plugs, data connections (RJ45, TV, HDMI, etc.) and smaller distributions, such as compressed air connections. The level-adjustable sockets can be easily adapted to the finished floor level and filled with the desired floor covering.

Individually combinable: various socket outlet systems with hinged or screw-on lids

For your outdoor power supply, rely exclusively on high-quality products such as the various socket outlet systems with the designations FONTO and MASSO. The models in the FONTO series are available with both hinged and screw-on lids.

Bodensteckdosen mit Schraubdeckel offen und oder mit befüllbarem Klappdeckel

These are floor-level socket outlets that can be driven over when closed and are ideal for supplying power to wet sweepers and other electrical systems. Alternatively, you can also obtain micro-drop distributors that can be installed flush with the floor. The complete floor box systems of the FONTO 9301 / 9308 series, consisting of stainless steel or die-cast aluminum sockets, are suitable for indoor use and are suitable for a wide range of applications inside buildings. These models are characterized by high-quality device carriers made of aluminium, lids for mounting and various configurations with earthed plugs, network connections and other media. Thanks to the special design, the sockets can also be used when closed. This is made possible by the individually assignable openings for cable entry integrated into the device covers.

Have we piqued your interest and do you need more information about our floor sockets?

Do you need ready-to-use floor sockets for indoor or outdoor use? Then take a look at our portfolio and contact us if you have any questions or require information. Our team at GIFAS ELECTRIC will provide you with professional and competent advice.

May we advise you free of charge and without obligation?

Our electricity experts look forward to hearing from you and developing a customized concept for you.

Alternative distribution solutions for indoor and outdoor use:

Breite silberne Energiesäule aus robustem Aluminium-Gehäuse mit Schuko, CEE, Datenanschluss RJ45 und Sicherungskasten bestückt

Energy columns

individual equipment, design up to 6m,
optionally with light element, aluminum profile

Schwarze Edelstahl-Unterflurverteiler aufgeklappt mit Edelstahlkorpus und einmal auf Beton-Ring montiert

Underfloor distributors

Individual assembly, up to 900kN, Electrical distribution SKII, wired ready for connection

LED Mastleuchte in hellgrau für Straßen und Parkplätze mit Sensor-Technik. Moderne Technik in schlankem Design

Wall-mounted distributors

Individually equipable solid rubber distributor
with Schuko and CEE
